Diamond Segment for Cutting Granite Marble and Sandstone

Quanzhou Sang Diamond Tools Co., Ltd.
  • Type:Diamond Segment
  • Surface Finishing:as Request
  • Blade Material:Diamond
  • Certification:SGS, ISO
  • Qaulity:a
  • Size:All Sizes Can Be Produced

Base Info

  • Model NO.:diamond segment
  • Usage:Stone Cutting
  • Manufacturing Arts:Sinter
  • Kind:Stone Sawing Machine
  • Transport Package:Carton, Wooden Box
  • Specification:ISO, SGS
  • Trademark:SANG
  • Origin:Fujian, Quanzhou
  • HS Code:82079010
  • Production Capacity:300000PCS,Month

Description

Basic Info.

Model NO. diamond segment Usage Stone Cutting Manufacturing Arts Sinter Kind Stone Sawing Machine Transport Package Carton, Wooden Box Specification ISO, SGS Trademark SANG Origin Fujian, Quanzhou HS Code 82079010 Production Capacity 300000PCS/Month

Product Description



Advantage:
1.Long lifespan formular
2.High daily output
3.Strict quality control
4.Quick delivery 5-7 days
Points
** The segments are attached to the core by brazing with silver solder;
**High-quality Diamond Segment Made from high-grade Diamond by special and advanced technics;
**Segment  for diameter 300mm to 4200mm;
**Specifications supplied by customers are available;
**Segment can be produced for single blade, multi-blade;
**Professional formula are used coorespondently for cutting granite , marble,limestone, Lava stone,onxy,con;
**DImaonds and bond in the outer and inner layers are carefully designed to ensure cutting stability;
Item No.Diameter
(mm)
Steel Core Thickness(mm)Segment Dimension (mm)Segment No.
SGS-SGM300Φ3002.240×3.2×8(10)22
SGS-SGM350Φ3502.440×3.4×8(10)25
SGS-SGM400Φ4002.640×3.6×8(10)29
SGS-SGM450Φ4502.8/3.040×4.0×8(10)32
SGS-SGM500Φ5003.0/3.240×4.2×8(10)36
SGS-SGM600Φ6003.6/3.840×4.8×8(10)42
SGS-SGM700Φ700440×5.2×8(10)42
SGS-SGM800Φ8004.540×6.0×8(10)46/57
SGS-SGM9009005.0 24×7.5×8(10,12)64
SGS-SGM100010005.0 24×7.5×8(10,12)70
SGS-SGM120012005.5 24×8.5×8(10,12)80
SGS-SGM130013006.0 24×8.5×8(10,12)88
SGS-SGM140014006.5 24×9.0×8(10,12)92
SGS-SGM160016007.2 24×9.5×8(10,12)108
SGS-SGM180018007.5 24×10.0×8(10,12)120
SGS-SGM200020008.0 24×10.5×8(10,12)128
SGS-SGM220022009.0 24×11.0×8(10,12)132
SGS-SGM250025009.0 24×11.0×8(10,12)140
SGS-SGM300030009.5 24×12.0×8(10,12)160
