How to plug in the M2 interface: hot topics and practical guides on the Internet
Recently, with the popularity of solid-state drives (SSDs), the installation issue of the M.2 interface has become a hot topic among technology enthusiasts and DIY users. This article will combine the hot content of the entire network in the past 10 days to analyze in detail the installation steps, frequently asked questions and purchase suggestions of the M.2 interface, and attach structured data for reference.
1. Basic knowledge of M.2 interface
M.2 is a new solid-state drive interface standard that supports NVMe and SATA protocols. It is small in size and powerful in performance. Here is a comparison of two common types of M.2 interfaces:
| Type | Agreement | speed | Applicable scenarios |
|---|---|---|---|
| M.2 SATA | SATA III | About 550MB/s | Daily office, light use |
| M.2 NVMe | PCIe 3.0/4.0 | Up to 7000MB/s | High-load tasks such as gaming and video editing |
2. M.2 interface installation steps
The following is the most discussed M.2 installation process on the Internet:
1.Confirm motherboard compatibility: Check whether the motherboard supports the M.2 interface and protocol type (NVMe or SATA).
2.Preparation tools: Screwdriver, M.2 screws (usually included with the motherboard).
3.Installation steps:
- Disconnect power and discharge static electricity;
- Find the M.2 slot on the motherboard;
- Insert the SSD at a 30-degree angle and press lightly until the buckle is secure;
- Secure the tail with screws.
3. Summary of recent popular issues
According to social platform and forum data in the past 10 days, the following are the M.2-related issues that users are most concerned about:
| question | frequency of occurrence | solution |
|---|---|---|
| The system does not recognize it after installation | 35% | Check BIOS settings and update drivers |
| Screws are missing or slipped | 28% | Purchase an M.2 screw kit or use electrical tape to temporarily secure |
| The speed is not as fast as expected | 22% | Confirm protocol match (e.g. PCIe 3.0 vs 4.0) |
4. Purchasing suggestions and popular products
Combining e-commerce platform sales and evaluation data, M.2 SSDs worthy of attention in the third quarter of 2023:
| brand | Model | Capacity | Reading speed | price range |
|---|---|---|---|---|
| Samsung | 980 Pro | 1TB | 7000MB/s | ¥600-800 |
| Western Digital | SN770 | 1TB | 5150MB/s | ¥400-600 |
| To titanium | TiPlus7100 | 1TB | 7000MB/s | ¥500-700 |
5. Things to note
1.Heat dissipation problem: It is recommended to install a heat sink for high-performance NVMe SSD. The motherboard’s built-in heat dissipation armor needs to be removed from the protective film.
2.System migration: It is recommended to use professional tools such as Macrium Reflect when cloning old hard drives.
3.Slot priority: Some motherboards share bandwidth with multiple M.2 slots. It is recommended to give priority to the slot directly connected to the CPU.
Through the above structured data and step analysis, I believe you can easily complete the installation and optimization of the M.2 interface. For further discussion, please refer to the recent #SSD installation topic on Zhihu or related video tutorials on Bilibili.
