Diamond Tools

230mm Sinter Hot-Pressed Granite Saw Blade

Shijiazhuang Corediam Tools Technology Co., Ltd.
  • Blade Type:Turbo Segment & Protective Segments
  • Manufacturing Process:Sintered
  • Application:Stone
  • OEM Service:Acceptance
  • Suitable:Wet and Dry Cutting
  • Transportation:Ocean, Land, Air

Base Info

  • Model NO.:STBC
  • Certificate:En13236
  • Manufacturing:Sinter Hot-Pressing
  • Transport Package:Carton
  • Specification:105-350MM
  • Trademark:COREDIAM
  • Origin:China
  • HS Code:82023910
  • Production Capacity:10000PCS,Month

Description

Basic Info.

Model NO. STBC Certificate En13236 Manufacturing Sinter Hot-Pressing Transport Package Carton Specification 105-350MM Trademark COREDIAM Origin China HS Code 82023910 Production Capacity 10000PCS/Month

Product Description

230mm Sinter Hot-Pressed Granite Saw Blade

1. Introduction


This type of blade is light and easily-carried, the diameter is 300mm. The manufacture of art is sintered hot-pressed.
It can be widely used in wet cutting granite, marble and other stone materials with good efficiency. It is sinter hot-pressed. The segment height is 12mm.  The quality level is premium. This type blade is with wave steel core. Turbo segments for better cooling and better dust removal, the deep segments can well be protected the blades from undercutting.

230mm Sinter Hot-Pressed Granite Saw Blade

2. Specification  for reference: (others also available as per required)

Item No.DiameterSegment HeightSegment WidthArbor
STBC10509105mm9mm2.2mm22.23mm
STBC11509115mm9mm2.2mm22.23mm
STBC12509125mm9mm2.2mm22.23mm
STBC15009150mm9mm2.2mm22.23mm
STBC18009180mm9mm2.5mm22.23mm
STBC23009230mm9mm2.7mm22.23mm
STBC30012300mm12mm3.0mm25.4mm
STBC35012350mm12mm3.0mm25.4mm

230mm Sinter Hot-Pressed Granite Saw Blade

3. Features:

 - Universal dry and wet cutting blades.
 -small cutting width

 - Turbo segment for better cooling and better dust removal, the deep segment style can well be protected the blades from undercutting.
- The wave steel core improves blade rigidity, reduces friction, avoids wobbling during cutting and is a better removal of filings.

230mm Sinter Hot-Pressed Granite Saw Blade

4.Turbo blade production process.


Raw material→ powder mixing→steel core→cold press→sintering→surface treatment→packaging→dispatch

230mm Sinter Hot-Pressed Granite Saw Blade

5. Delivery time

Sample delivery: If we have stock, the delivery time is within one week after we got your sample payment.
If we don't have stock, the delivery time will depend on the sample production.

For batch order, delivery time is usually 3-4 weeks after order confirmation and payment.



230mm Sinter Hot-Pressed Granite Saw Blade

6. Production facility


230mm Sinter Hot-Pressed Granite Saw Blade

7.Corediam introduction

Corediam Tools Co., Ltd., as a high-tech enterprise, concentrates on researching & developing manufacturing and marketing diamond tools industry. We have the most extensive, innovative and powerful range of diamond tools for construction, stone and DIY markets. Corediam strives to be the leading professional supplier in the world through technology innovation.
